技术参数：
内径百分表；刻度:0.01mm(0.0005")；表面刻度盘:57mm(2-3/16")；度数:0-100(0-25-0)；每转速行程(Travel Per Rev)：1mm(0.05")；总行程(Total Travel):3mm(0.25")；范围:35-50mm；孔深度：240；重量:0.95kg；品牌：英国
产品描述：
尚尤为您提供内径百分表，此款产品的具体介绍如下：
1.适用于快速、准确的测量大小，同心度，磨损，锥度，等等。适合车间和检验用。
2.所有型号都有一个固定的一个移动砧和自我调节的中心管。
3.“基准点” 可以使用直径为已知的设置环或千分尺进行设置。
4.“零”到此基准点，通过旋转边框对齐零与指标。
Suitable for rapid, accurate measurement of size, concentricity, wear, taper, etc., in a wide range of bores. For workshop and inspection use. All models have one fixed and one moving anvil and a
self-adjusting centre shoe. A ‘datum point’ can be set by using a setting ring of a known diameter or a micrometer. ‘Zero’ the gauge to this datum point by rotating the bezel to align ‘zero’ with the indicator. To check a bore is within tolerance, the limit hands can be fixed as required. All anvils are spring loaded to expand into the bore.
For accurate reading ensure the stem of the gauge is parallel to the axis of the bore. This can be checked by ‘rocking’ the gauge back and forth until the smallest diameter is found. All models have interchangeable anvils to cover a range of bore sizes.
