技术参数:
可反转快速风动棘轮扳手;空载转速:150rpm;进气口螺纹:1/4"NDP;最小空气软管尺寸(ID):10mm(3/8");空气压力:6.2bar(90PSI);耗气量:4CFM(113Ltr/min)*;振动水平:4m/s²;工作扭矩范围:50ft/lbs;总长:255mm;方形驱动(square drive):1/2";螺栓能力(bolt capacity):13mm;声功率级:89dBA;声压/噪音的水平:89dBA;品牌:英国
产品描述:
尚尤为您提供可反转快速风动棘轮扳手,此款产品采用球型的固定器,可反转使用,结构紧凑,轻巧的设计,非常适合汽车行业使用。
产品规格:
空载转速:150rpm。
进气口螺纹:1/4"NDP;
最小空气软管尺寸(ID):10mm(3/8")。
空气压力:6.2bar(90PSI)。
耗气量:4CFM(113Ltr/min)*
振动水平:4m/s²。
工作扭矩范围:50ft/lbs;
总长:255mm
Ball type retainer, disc type reversing action, compact, lightweight design, ideal for automotive work.
Specifications:
10mm bolt capacity.
1/4" NPT air inlet thread for 10mm air hose.
150rpm free speed.
90psi air pressure.
4CFM* air consumption.
50ft/lbs torque.
Front exhaust
Overall length: 255mm.
